The Chatsworth Monitored eConnect PDU delivers intelligent power monitoring and secure distribution for high-density IT environments. Designed in a 2U horizontal form factor, this PDU features an IEC 32A 1P+N+E input, supporting up to 6.1kW (UL) or 7.7kW (CE) of power capacity. With ±1% metering accuracy and an onboard LCD display, real-time power tracking is effortless, ensuring optimal energy management.
Equipped with (18) C13 and (6) C19 locking outlets, this PDU prevents accidental disconnections while providing stable power delivery to critical IT infrastructure. Secure Array IP Consolidation simplifies network management, while integration with SNMPv1/v2/v3, RESTful API, CLI, LDAP, and RADIUS enables seamless remote control.
The field-replaceable controller enhances serviceability, and environmental sensor and electronic lock integration readiness ensure future scalability. Built with 100% rated hydraulic magnetic breakers for superior overload protection, this PDU operates reliably in environments up to 149°F (65°C).
FEATURES:
- Horizontal 2U monitored PDU with secure power management
- (18) C13 + (6) C19 locking outlets for stable connections
- ±1% metering accuracy with an integrated LCD display
- IEC 32A 1P+N+E input with up to 7.7kW capacity
- Secure Array IP Consolidation for network efficiency
- Onboard GUI, SNMPv1/v2/v3, RESTful API, and CLI support
- LDAP & RADIUS authentication with HTTPS security
- Environmental sensor & electronic lock integration ready
- 100% rated hydraulic magnetic breakers for safety
SPECIFICATIONS:
- Input Type: IEC 32A 1P+N+E
- Outlets: (18) C13 + (6) C19 locking outlets
- Maximum Power Capacity: 6.1kW (UL) / 7.7kW (CE)
- Metering Accuracy: ±1%
- Display: LCD for local monitoring
- Communication: 10/100/1000MB port, SNMPv1/v2/v3, RESTful API, CLI
- Authentication: LDAP & RADIUS integration, HTTPS
- Operating Temperature: Up to 149°F (65°C)
- Breakers: 100% rated hydraulic magnetic
- Form Factor: Horizontal 2U
- Color: Black
WARRANTY:
1-Year Limited Warranty
