Optimize your data center's efficiency with the Chatsworth Monitored Pro eConnect PDU, a high-performance vertical power distribution unit designed for 42U and higher cabinets. This intelligent PDU features a 220-240V 1P/15A IEC 60309 input with a C20 inlet, delivering 3.8kW of reliable power capacity. Its ±1% metering accuracy and LCD display provide precise real-time monitoring for superior energy management.

Equipped with (18) C13 and (6) C19 locking outlets, this PDU ensures secure power distribution while preventing accidental disconnections. Secure Array IP Consolidation enhances network efficiency, while SNMPv1/v2/v3, LDAP, and Radius integration allow seamless remote access and control.

With environmental sensor and electronic lock integration readiness, this PDU is built for future scalability and enhanced security. The field-replaceable controller ensures easy maintenance, and tool-less vertical mounting simplifies installation. Built to withstand temperatures up to 149°F (65°C), it provides reliable operation in demanding environments.

FEATURES:

• Vertical monitored PDU for 42U & higher cabinets
• (18) C13 + (6) C19 locking outlets for secure power delivery
• ±1% metering accuracy with an integrated LCD display
• 220-240V 1P/15A input with C20 inlet, 3.8kW capacity
• Secure Array IP Consolidation for network efficiency
• Onboard GUI, SNMPv1/v2/v3, LDAP, and Radius integration
• Environmental sensor & electronic lock integration ready
• 100% rated hydraulic magnetic breakers for protection
• Tool-less vertical mounting for easy installation

SPECIFICATIONS:

• Input Type: 220-240V 1P/15A IEC 60309
• Inlet: IEC C20
• Outlets: (18) C13 + (6) C19 locking outlets
• Maximum Power Capacity: 3.8kW
• Metering Accuracy: ±1%
• Display: LCD for local monitoring
• Communication: 10/100/1000MB port, SNMPv1/v2/v3
• Authentication: LDAP & Radius integration, HTTPs
• Operating Temperature: Up to 149°F (65°C)
• Breakers: 100% rated hydraulic magnetic
• Mounting: Vertical, tool-less installation
• Color: Black

WARRANTY:

1-Year Limited Warranty
